No.

Name

Model

1

Engine System

Engine (Made in China)

Rated power:155kW/2000 rpm Max Torque:

930N.m/1300-1500rpm

2

Hydraulic system

Main winch

Reel

Pitch:21.2,
Rope capacity:250m

Reducer

Max displacement:80ml/r
Rated pressure:35MPa

Motor

Speed Ratio:50.52
Max output torque:16732N.m
Max output speed:73.6rpm

Balance valve

Max flow:350L/min
Max pressure:35MPa

Auxiliary winch

Reel

Pitch:21.2,
Rope capacity:250m

Motor

Max displacement:80ml/r
Rated pressure:35MPa

Reducer

Speed Ratio:50.52
Max output torque: 16732N.m
Max output speed:73.6rpm

Balance valve

Max flow:350L/min
Max pressure:35MPa

Luffing winch

Reel

Pitch:21.2,
Rope capacity:100m

Motor

Max displacement:80ml/r
Rated pressure:35MPa

Reducer

Speed Ratio:50.52
ax output torque: 17314N.m
Max output speed:46.3rpm

Balance valve

Max flow:350L/min
Max pressure:35MPa

Slewing

Motor

Rated displacement:63ml/r
Rated pressure:35MPa

Reducer

Speed Ratio:117.55
Max output torque:22805N.m
Max output speed:17rpm

Traveling

Motor

Displacement:107ml/r
Rated pressure:35MPa

Reducer

Mmax:80000Nm

Pump Group

Main pump

Max displacement:107ml/r
Rated pressure:35MPa

Valve Group

Main valve

Max flow:400L/min
Rated pressure:35MPa

3

Electrical System

Torque limiter

4

Slewing system

Slewing bearing

5

Crawler traveling device

Drive wheel

Amount:2

Guide wheel

Amount:2

Drag chain wheel assembly

Amount:4

Idler wheel

Amount:20

Track plate

Amount:122
